General GM9 Condenser Microphone

GM9 General Condenser Microphone

Instructions for use (Windows 10 as an example)

1. The product can be used when it is powered on.

2. Listen ON/OFF

Go to the computer [Sound] > [Select Input Device], set the product as the input device.

Click [Device Properties] > [Other Device Properties] to open the Microphone Properties dialog box.

Input

Choose your input device
(GM9)

Certain apps may be set up to use different sound devices than the one selected here. Customize app volumes and devices in advanced sound options.
Device properties

3.Click [Listen], check [Listen to this device], set [MC001] as the current speaker of the computer, and save the settings.

3. Mute/Noise Switch

Function

Turn on/off Mute

Turn on/off Noise Reduction

Operation

Press the mute button once

Press the noise button for 3 seconds

Indicator light

Red light is on/off

The red-light flashes fast 2 times/3 times

Kind Tips

1. Please unplug the power cord when the product is not used for a long time.

2. Do not tap the microphone during use to avoid damaging the components and affecting the sound quality.

3. The best distance for microphone pickup is 3-10cm. Do not use the microphone with your mouth.

Specifications

1. Sampling rate: 24bit/48KHz

2. Directions: omnidirectional

3. Frequency response:

100-15000Hz

4. SNR: >72dB

5. Compatible systems: Windows 7/8.1/10/Linux/macOS, etc

6. Compatible devices: PC devices and mobile phones

Packing List

Desktop*1
USB-C data cable*1
Connection diagram
Microphone
(Adjustable angle for voice pickup)
Indicator light
Mute/Noise button
3.5mm monitoring port
USB-C port
207m mm
USB cable
Computer Phone

Note: When connecting the mobile phone, please use it with an OTG adapter
