Godox Ving V480C TTL On-Camera Flash for Canon

Godox Ving V480 Overview

A Guide to On-Camera Flash

Read More

From Manufacturer

02:07

Introducing Godox TTL Li-ion Camera Flash V480

04:00

Operation Tutorial-TTL Li-ion Camera Flash V480

Delivering plenty of light in a portable flash body, the Ving V480C TTL On-Camera Flash from Godox combines their 2.4 GHz X system for wireless flash control and TTL auto flash capability. The V480C is compatible with Canon E-TTL / E-TTL II and also offers manual, multi, HSS, and second curtain sync characteristics. The V480C is similar to the Godox V860III and V350 flash units— smaller than the V860III and bigger and more powerful than the V350—designed as a medium-size, compact, yet powerful lighting solution with advanced features. A convenient LED modeling light is located right in the center of the flash body. Experience fast recharge and long-lasting shoots with a versatile flash head that tilts from -7 to 120° and rotates 330°. The flash runs on an included rechargeable battery to allow recycling times of 1.7 sec, providing enough energy for up to 650 full-power flashes. The V480C comes with a detachable battery, a USB-C cable, a power adapter, as well as a mini stand and a pouch.

Greater Lighting Control

Canon E-TTL / E-TTL II-compatible, the Ving V480C flash offers support for high-speed sync, 2nd curtain sync, and much more. The flash can be used in manual mode or programmed to fire multiple stroboscopic flashes, and it can also function with high-speed sync for quicker shutter speeds. On top of this, the flash features a guide number of 164' at ISO 100 along with flash durations from 1/600 to 1/20,000 sec, and adjustable output from 1/256 to full power.

Flexible Design

The V480C is useful for both on-camera and off-camera operation. The flash will provide ample illumination for most subjects. It features a convenient auto/manual zoom head with a range of 24-105mm, a white catchlight panel, and a built-in wide-angle diffuser. The head can be tilted from -7 to 120° and rotated 330° to control bounce and where the light falls on the scene.

2.4 GHz X Wireless Radio System

The Godox 2.4 GHz X wireless radio system makes it compatible with Godox's X series transmitters for more advanced functionality and setups. The wireless control of the V480C enables 2.4 GHz wireless flash triggering to extend your shooting possibilities. The flash works with the separately purchased XPro II, X2, and X3 Godox models. With a wireless range of 328', the V480C lets you choose between 32 channels and set up five groups.

Effective Battery Power

A 7.2V, 2200mAh lithium removable battery is supplied with recharge times of 1.7 seconds, providing approximately 650 full-power flashes per charge. Godox also includes the USB-C cable and power adapter in the box.

Control at Your Fingertips

Ideal for photographers in need of both simple and elaborate lighting setups, the V480C has an easy-to-use design with onboard controls, a 2" touchscreen interface, and a universal shoe-mounted connection for a wide range of Canon cameras. Additionally, indicators on the LCD panel inform you of the remaining battery level.

Stable Continuous Shooting

The V480C maintains a stable color output and brightness in high-speed continuous shooting.

LED Modeling Light

A 2W LED modeling light with adjustable brightness is integrated into the flash body with 5300K (+/-300K) CCT.

Firmware Updates

Firmware updates are available via its USB-C port for compatibility with the latest camera models and optimal performance.

Additional Details

• S1 and S2 settings
• First and second curtain sync
• +/- 3-step of flash exposure compensation in 1/3 increments
• Multi-stroboscopic flash mode up to 100 times, 100 Hz
• TCM converter capability
• Wi-off mode
• Standby and screen lock
• Power switch and auto-off ability
• Hot shoe connection
• 2.5mm sync cord jack for connecting an optional sync cable
• Overheating protection
• Lightweight at 12.7 oz with the battery included

Items Included

• Godox Ving V480C TTL On-Camera Flash for Canon
• Diffuser
• Battery
• USB-C Cable
• Power Adapter
• Mini Stand
• Pouch
• Limited 1-Year B&H Warranty
